Hydraulic systems, often found in machinery and equipment, rely on the seamless connection of hoses and tubes to transport fluids. The quality and type of fitting chosen can significantly influence the performance, safety, and longevity of the entire hydraulic system. In this guide, we deep dive into the STAMP method and explore the most popular hydraulic hose fittings.


1. The STAMP Method

The STAMP method stands for Size, Temperature, Application, Media, and Pressure. This approach is essential in selecting the right hydraulic hose fitting, ensuring a leak-free connection that is apt for a specific application.

Popular Hydraulic Fitting Styles

The three most ubiquitous hydraulic fitting styles are: -O-ring, -Mated Angle, -Tapered Thread


2.1 -O-ring Fittings

O-ring fittings come in three main designs:

O-ring Boss (ORB) Fittings: For hydraulic cylinder rebuild These have an O-ring seated between the threads and wrench flats. The O-ring is around the male threaded end’s outer diameter and seats against the female port, ensuring a robust leak-tight seal. They can be either adjustable or non-adjustable. Adjustable versions are generally elbows or tees that require alignment before tightening, while non-adjustable versions are straight connectors or plugs.

O-ring Face Seal (ORFS) Fittings: In this design, the O-ring is located on the fitting’s face, creating a seal between two metallic surfaces. When tightened, the O-ring compresses against the mating fitting. These fittings are becoming increasingly popular due to their resistance to high-vibration applications. Material and temperature considerations: The operating temperatures for these fittings depend on the O-ring seal materials. For example, the commonly used Nitrile 90 Durometer O-rings are suitable for ORFS fittings, but high-temperature applications might require materials like fluorocarbon.


2.2 Mated Angle Fittings

Two popular types are: JIC 37-degree Flare Fittings: Ideal for high-pressure applications in heavy machinery, these fittings have a flared end that fits into flared tubing. This connection forms a leak-tight seal when tightened with a threaded nut; they are commonly used when we are providing hydraulic cylinder rebuild services. They are interchangeably known as flare fittings, SAE 37-degree tube fittings, or SAE J514 fittings.

SAE 45-degree Flare Fittings: Used predominantly in low-to-medium pressure applications, these fittings have a 45-degree flare seating surface. They are not interchangeable with JIC fittings due to the different flare angle. Made mostly of brass, these fittings are suitable for a wide range of temperature applications but have pressure limitations at extreme temperatures.


2.3 Tapered Thread Fittings

Tapered threads, such as NPT, BSPT, and Metric, create a metal-to-metal pressure-tight seal. They need a thread sealant, like Teflon tape, to ensure a leak-free connection. Their effectiveness lies in the male and female threads compressing and wedging together.

The most common tapered thread in North America is the NPT and we stock NPT for hydraulic cylinder rebuild services. However, it’s essential to note that NPT threads are incompatible with BSPT or Metric threads, which are more prevalent in Europe.


3. Choosing the right hydraulic hose fitting is pivotal for the safety and efficiency of hydraulic systems.

By understanding the different types of fittings and their applications, one can ensure optimal performance and longevity of the equipment. Whether it’s an O-ring, mated angle, or tapered thread, each fitting has its unique advantages and applications. Always consider the STAMP method and consult with experts when in doubt.

JIC 37° Flare vs. O-ring Face Seal Hydraulic Fittings: A Comparative Guide

When it comes to hydraulic fittings and hydraulic cylinder rebuild, the debate between JIC 37° flare and O-ring face seal (ORFS) often arises. Drawing a parallel to the automotive world, comparing these fittings is akin to contrasting a Mercedes-Maybach S with a Porsche 911 Turbo. Both are exquisite, high-end options, but they cater to different needs and preferences. The Maybach epitomizes luxury, while the Porsche symbolizes sportiness. Similarly, while both JIC and ORFS fittings are effective, their application and features vary. JIC 37° Flare Fittings, Overview: JIC fittings, characterized by their 37° flare cone, primarily form a metal-to-metal seal. They are the most prevalent hydraulic connection style. These fittings typically connect to either a flared tube or hose fitting, and often serve as adapters for female SAE swivels, introducing versatility to the system. Specifications: Governed by the SAE J514 and ISO 8434-2 standards, these 37° flared connectors are designed for general and dimensional requirements. Compatible with ferrous and non-ferrous tubes ranging from 15/64″ (6 mm) to 2″ (50.8 mm). Suitable for fuel delivery and fluid power applications at pressures up to 7,700 PSI.

Temperature compatibility ranges from -425°F (-254°C) to 1200°F (649°C) with stainless steel variants. Advantages: Economically priced. Versatile connectivity across various hydraulic systems. Exceptional performance across temperature gradients, especially at high pressures Widely accepted in most hydraulic applications, we stock a large amount of JIC fittings for hydraulic cylinder rebuild services here at Ames Hydraulics. Commonly used in industries like military, aerospace, plumbing, construction, and more.


2. O-ring Face Seal (ORFS) Fittings, Overview:

ORFS fittings are characterized by a recessed O-ring on the fitting face, designed to eliminate leakage in high-pressure hydraulic systems. The seal’s recessed design prevents leakage and offers protection against over-torquing. Specifications: Governed by SAE J1453 and ISO 8434-3 standards, these fittings set the benchmark for O-ring face seal fittings. Primarily used in fluid and gas transfer systems that experience vibrations, with a pressure tolerance of up to 6,000 PSI and commonly in stock for hydraulic cylinder rebuild. Stainless steel variants can handle temperatures ranging from -425°F (-254°C) to 1200°F (649°C). The O-ring material, often FKM/Viton® or Buna-N/Nitrile, dictates the assembly’s temperature rating. Advantages: Hassle-free assembly, Resilient against vibrations, High-pressure compatibility, Reusable without limitations, Zero-gap component ensures robust sealing, Commonly used in shipbuilding, petrochemical, off-road, construction, and agricultural industries.

3. In the realm of hydraulic fittings, neither JIC nor ORFS is inherently superior.

Much like choosing between a luxury sedan and a sports car, the decision rests on the specific application and user preference. While JIC fittings have established themselves as an industry staple due to their dynamic sealing properties and affordability, ORFS fittings are revered for their impeccable sealing, especially in high vibration settings. Making an informed choice between the two requires understanding the specific needs of the hydraulic system and the advantages each fitting offers.
